NMEA Server Enable
4
Choice
Core
"No", "Yes"
Enables or disables the NMEA server on the controller
NMEA Server Interval
1
Integer
Core
0 to 65536
NMEA server broadcast interval in seconds
NMEA Server Message Source
4
Choice
Core
“Controller”,
“Echoed”
The source of the NMEA messages sent to the configured
port. “Echoed” indicates a message echoed from a GPS
device
NMEA Server Com Port
Settings
4
String
Core
-
Com port setting or TCP-IP port number to use for NMEA
server on the controller
6.8.2 Slide Motor Feed System
Note Many of these options are found under the “Core” tab.
Long name
Level
Type
Category
Value Range
Documentation
SlideMotor Abs Enc Offset
4
Float
Sensor
-600.0 to
600.0
The offset in degrees to be added to the read position of
the absolute encoder.
SlideMotor Abs Enc Scale
Factor
4
Float
Sensor
-10000.0 to
10000.0
The scale factor that will be multiplied to the raw absolute
encoder or resolver value.
Slide Motor Enable
4
Choice
Feed
“No”, “Yes”
Slide Position Enable (No = slide is disabled)
Slide Motor Stow Position
4
Choice
Positioner
“None”, “1”,
“2”, “3”
Slide position to move to before a stow completes
SlideMotor Scale Factor
4
Float
Sensor
-10000.0 to
10000.0
The scale factor to divide by to produce the actual value.
SlideMotor Switch 1 (through
3) is Interlock
4
Choice
Sensor
“No”, “Yes”
Flag indicating the digital input as an interlock (blocks other
operations when set
Slide Position 1
4
Float
Modules
-100.0 to
100.0
Numeric slide position representing the left slide position
Slide Position 2
4
Float
Modules
-100.0 to
100.0
Numeric slide position representing the center slide
position
Slide Position 3
4
Float
Modules
-100.0 to
100.0
Numeric slide position representing the right slide position
6.8.3 Vector Compass
Long name
Level
Type
Category
Value Range
Documentation
Vector Compass Enable
1
Integer
Core,
Sensor
0 or 1
Flag indicating that the compass should be used and
powered (1 = powered)
Vector Compass Heading
Offset
4
Float
System
-180.0 to
180.0
The offset in degrees of the device
Vector Compass Com Port
4
String
System
-
The filename for the com port used
Vector Compass Com Port
Settings
4
Choice
System
“No”, “Yes”
The computer settings for the com port, in the form of Baud,
Data, Stop & Parity Bits (ie: 9600 8 1 0) where parity values
are 0 for none and 1 for even.
Vector Compass Reset
1
Integer
Sensors
0 or 1
Flag indicating that the compass should be reset. ( 1 = reset
now)
Vector Compass Scan Width
1
Float
Modules
0.0 to 400.0
Scan width used during a SatTant or 0.0 to disable SatTant
Vector Compass Separation
4
Float
Modules
0.0001 to
10.0
Separation parameter used to initialize the vector compass
