AvL Technologies AAQ Antenna Controller User Manual

AvL Proprietary and Confidential
Content is Subject to Change without Notice Page 23 of 195
Once the installation is complete, a shortcut to the program will be located on the desktop.
Figure 3.2.2b - Remote Icon
3.2.3 AAQ Remote Access Settings
The AAQ Controller allows for different user interactions based on the access level of the user. This
allows for the end user to engage in a simple to use experience (level 0), while keeping the
customization available for knowledgeable users with higher level login privileges. The AAQ Remote
application incorporates these login level rules. Depending upon the login level of the user various
tools and interactions will become available.
Note - Integrators are typically set to access level 4 from the factory.
3.2.4 AAQ Remote Settings (Access Level 0)
The Remote Settings window displays the IP address, directing the Graphical User Interface
(GUI) to the AAQ antenna controller unit (ACU). The default service address is shown.
Path
Main Window → File → Settings
AAQRemote Settings
Figure 3.2.4 - AAQ Remote Settings (Level 0)
