AvL Technologies AAQ Antenna Controller User Manual

AvL Proprietary and Confidential
Content is Subject to Change without Notice Page 49 of 195
Figure 4.3.5 – RIOM Software Upload
From the RIOM Software Maintenance window, the user can update specific RIOM based devices on the
system. When the “Upload RIOM Payload” button is pressed, the user is prompted to pick the location
of the new file via a Windows location dialog box. Once the upload(s) are completed, the files will be
shown in the “payload” box.
To program individual RIOMs, first make sure that the correct files have been uploaded. Then check the
appropriate box in the right-hand pane for the device(s) to be updated. For each RIOM device, use the
pulldown to select the appropriate file and press “Program RIOM(s) when ready
4.3.6 Show Movement
Path
Main Window → File → Show Movement
Level 4
