6.4.1 Target Satellite
Long name
Level
Type
Value Range
Documentation
Current Satellite Inclination
1
Float
-100 to 100
The inclination of the current satellite. (degrees)
Current Satellite
1
String
-
The longitude of the satellite to target during acquire
with the numeric portion in decimal degrees and the
hemisphere as a single letter (ie 61.5 W).
Current Satellite Polarization
1
Choice
"Horizontal",
"Vertical"
Feed orientation for the selected satellite
(Horizontal/Vertical).
Reference Profile 1
1
Choice
All Listed
First reference profile used to perform a Ref Sat
Acquisition
Reference Profile 2
1
Choice
All Listed
Second reference profile used to perform a Ref Sat
Acquisition
Reference Satellite Mode
4
Choice
"No", "Yes"
Flag indicating that reference profiles should be used if
a heading is needed.
Current Satellite Longitude
0
String
-
The longitude of the satellite to target during acquire
with the numeric portion in decimal degrees and the
hemisphere as a single letter (ie 61.5 W)
Current Satellite NORAD ID
0
Integer
0 - 999999999
The NORAD ID of the Satellite, Used For Target Updates
Current Satellite Polarization
0
Choice
“Horizontal”,
“Vertical”
Feed polarization for the selected satellite
Current Satellite TLE Line 1
0
String
-
Line 1 of the NORAD Two Line Ephemeris
Current Satelliite TLE Line 2
0
String
-
Line 2 of the NORAD Two Line Ephemeris
Run Repeak on Startup
4
Choice
“No”, “Yes”
Flag indicating whether the repeak command should be
run on startup if Rx is locked
Run Track After Acquire
1
Choice
“No”, “Yes”
Flag indicating that the Track Command should run
after a successful peak command
Run Track After Peak
1
Choice
“No”, “Yes”
Flag indicating that the Track Command should run
after a successful acquisition
Run Track on Startup
4
Choice
“No”, “Yes”
Flag indicating that the Track Command should run on
startup
Tracking Method
4
Choice
Choice of any
uploaded
Tracking
Module
Tracking Method to use after an Acquisition has been
completed
Update Heading After Acquisition
1
Choice
“No”, “Yes”
Flag indicating that the Heading should be recalculated
after an acquisition is completed.
Note – The three following parameters are entered automatically when a target
satellite is selected. These may be changed from the Satellite List.
Current Satellite Inclination should be set to the published value for the Target Satellite. If the
Target Satellite is listed as “Geostationary” and no inclination value is provided, then a value of “0.0”
is usually a good choice. If a successful acquisition is not consistently occurring on the first
Acquisition AZ line scan, then this satellite property should be verified by other means.
