AvL Technologies AAQ Antenna Controller User Manual

AvL Proprietary and Confidential
Content is Subject to Change without Notice Page 125 of 195
Coarse peaking Maximum Cycles sets the maximum number of Coarse Peaking cycles that may be
completed before the process is terminated. This parameter insures that the antenna does not fall
into an “infinite do loop” attempting to satisfy the Coarse Peak Signal Difference Threshold
parameter that may have been set too low for current conditions.
The Coarse Peak Signal Difference Threshold parameter establishes the success criteria for the
cyclical Coarse Peaking process. At the completion of each Coarse Peaking cycle, the final signal
level value achieved in the previous cycle is subtracted from the final signal value achieved in the
latest cycle. If the magnitude of that difference is equal to or less than the value of this parameter,
then the Coarse Peaking process is deemed to be complete. Else another Coarse Peaking cycle is
performed.
6.5.3 Fine Peaking
Long name
Level
Type
Value Range
Documentation
Fine Peaking Cycles
4
Unsigned
0 to 100
Number of cycles to complete for fine peaking. (0 =
1 az only, 1=1 az and 1 el only
Fine Peaking Mode
4
Choice
“None”, “CrossPattern”,
“StepPattern”, Plateau
Peaking
The selection of the peaking method used for fine
peaking routines.
Fine Peaking Maximum
Cycles
4
Unsigned
1 to 100
Maximum number of cycles to complete for fine
peaking stops.
Fine Peak Signal
Difference Threshold
4
Float
0.1 to 100.0
The amount of signal difference between peaking
iterations that will satisfy the system as the signal is
peaked.
Fine Peaking Cycles sets the minimum number of cycles that will be completed in the Fine Peaking
process regardless of any improvement made in antenna pointing (received signal level) at the
completion of each cycle.
Fine Peaking Maximum Cycles sets the maximum number of Fine Peaking cycles that may be completed
before the process is terminated. This parameter insures that the antenna does not fall into an “infinite
do loop” attempting to satisfy the Fine Peak Signal Difference Threshold parameter that may have been
set too low for current conditions.
The Fine Peak Signal Difference Threshold parameter establishes the success criteria for the cyclical
Fine Peaking process. At the completion of each Fine Peaking cycle, the final signal level value achieved
in the previous cycle is subtracted from the final signal value achieved in the latest cycle. If the
magnitude of that difference is equal to or less than the value of this parameter, then the Fine Peaking
process is deemed to be complete. Else another Fine Peaking cycle is performed.
