AvL Technologies AAQ Antenna Controller User Manual

AvL Proprietary and Confidential
Content is Subject to Change without Notice Page 133 of 195
Declination Override
4
Choice
"No", "Yes"
Flag indicating that the compass declination should
be ignored.
6.7.2 GPS
Long name
Level
Type
Value Range
Documentation
Manual Latitude
1
String
-
The latitude of the antenna to use if manual override for the
GPS is selected in decimal degrees and direction (ie: 109.2 N).
Manual Longitude
1
String
-
The longitude of the antennae to use if manual override for
the GPS is selected in decimal degrees and hemisphere
(ie: 99.2 E).
6.7.3 Tilt
Long name
Level
Type
Value Range
Documentation
Manual Pitch
4
Float
-180 - 180
Manually entered pitch angle in degrees used in tilt
override.
Manual Roll
4
Float
-180 - 180
Manually entered roll angle in degrees used in tilt
override.
Use Manual Tilt
4
Choice
"No", "Yes"
Flag indicating whether manual tilt values are used.
6.8 System Options
The following section addresses specific equipment and optionally installed AvL modules. Any changes to
parameters on systems where options are not installed will have no effect on operation.
6.8.1 NMEA Server
Long name
Level
Type
Category
Value Range
Documentation
NMEA Server Enable
4
Choice
Core
"No", "Yes"
Enables or disables the NMEA Server on the controller.
NMEAEchoInput Com Port
Settings
The communications parameters for the comm port in the
form of BaudRate DataBits StopBits Parity (ie 9600 8 1 0)
where parity values are 0 for none and 1 for even
NMEAEchoInput Com Port
4
String
Core
-
The computer device filename for the communications port
used.
NMEA Server Com Port
4
String
Core
-
Com port name (blank for IP address) to use for NMEA
server on the controller.
