AvL Technologies AAQ Antenna Controller User Manual

AvL Proprietary and Confidential
Content is Subject to Change without Notice Page 68 of 195
4.4.10 Device Window
Path
Main Window → View → Device window
Level 0
Figure 4.4.10 - Device Window, Modem Example
The Device Window displays the data and status of the connected “Signal Device” used for acquisition.
The module that handles communication from the AAQ to the device reports up to 8 predetermined
status labels and values. This information is placed in the “Device Data table” and can also be seen in
the
Sensor Output Window. When multiple devices are used for acquisition, the window will
automatically switch to the active device.
