Figure 3.5.4b - Cross Device Network Configuration Example
IPv4 Address: 192.168.1.2
Subnet Mask: 255.255.255.0
Computer
Modem
Network Switch
IPv4 Address: 192.168.1.1
Subnet Mask: 255.255.255.0
Network Router
IPv4 Address: 192.168.3.30
Subnet Mask: 255.255.255.0
IPv4 Address: 192.168.1.50 192.168.3.50
Subnet Mask: 255.255.255.0 255.255.255.0
Gateway: 192.168.1.1
AAQ Controller
External Network
