TWIN – Use and maintenance instruction manual
Chap. 4
- 14/20 -
TYPE OF
HOISTING
HANDLING
• Some machine structures or the machine body may be hoisted using a crane,
hooked up to the polyester straps (1) wound around the structures.
• Position the straps on the external part of the structures to be hoisted (2),
making sure they will not be crushed or come into contact with edges or
corners that may damage them.
• Rest the structures on wood supports (3) that make it possible to slip off the
polyester straps.
Handling using a lift-
truck and pipes
• Some machine structures may be hoisted using a lift-truck. The forks of the lift-
truck (1) must be positioned under the pipes (2) inserted in the special holes
on the machine structure.
2
1
1
3
2
