７‐１０
Press the E-key below the
icon when finished to go back to the Program list.
7. Use the up and down Jog keys to select the item you want to change.
：Sets the border width around the pattern in millimeters.
：Sets the border height around the pattern in millimeters.
：Sets the distance between patterns in the V(X) direction in millimeters.
*The distance is measured from the center of the patterns (start point).
：Sets the distance between patterns in the H (Y) direction in millimeters.
* The distance is measured from the center of the patterns (start point).
：Sets the pattern repetition in the V(X) direction.
：Sets the pattern repetition in the H(Y) direction.
8. Press the A-key below the icon for smaller number.
Press the B-key below the
icon for larger number.
Note: Press the D-key below the
icon
to change values using the Numeric Entry
Menu. *Refer to
Chapter 3 10. Numeric Entry Dialogue Box
.
9. Press the C-key below the
icon to set the border shape. (Square or circle)
10. Press the F-key below the icon to set the new values and view the changes made.
Note: The following Program parameters are automatically set with this feature.
#17: V repeat
#18: H repeat
#19: V space
#20: H space
