７‐１１
5. Automatic Matrix Embroidery Set Up
The feature automatically lays out the maximum number of patterns in the embroidery area.
*This setting resets Program settings #06: Socks and #15: Repeat.
1. Press the Design Edit Key,
.
2. Select a design and press the B-key below the
icon.
3. Use the Jog keys and to select item 16, Matrix.
4. Set the value to 1.
5. Press and hold the Origin key to save the change.
6. Press the F-key below the
icon to view the Automatic Matrix Embroidery Setup
screen.
Press the F-key below the
icon when finished to go back to the Program list.
7. Use the up and down Jog keys to select the item to change.
：Sets the V direction area of the Frame size in millimeters.
*The default value is the Frame limit settings, as set in MC.
：Sets the H direction area of the Frame size in millimeters.
*The default value is the Frame limit settings, as set in MC.
：Sets the distance between designs in the V(X) direction in millimeters.
