Barudan BEXS - Y Type Head

Y Type Head
The head cover on a Y head machine has a small removable door that lets you oil many
head components without removing the entire cover.
THE MACHINE SHOULD ALWAYS BE TURNED OFF BEFORE IT IS OILED.
OILING PROCEDURES ARE BASED ON AN 8 HOUR WORKDAY.
X Series Mechanical Guide 2-3
B2
F1
A1
B1
D2
E1
E1
D3
D3
B3
E4
E3
D2
E2
F1
B2
B2
B2
A1
C1
D1
