Barudan BEXS - Z Type Head

Z TYPE HEAD
Oiling Chart
PART IDENTIFICATION LUBRICANT FREQUENCY
Rotating Hook A1 Barudan machine oil
Clear (mineral) oil for sewing machinery
Every 4 to 6
hours
Drive Shaft B1 Barudan machine oil
Clear (mineral) oil for sewing machinery
Once a week
Hook Shaft Bushings (3) B2
*Needle Bars/Turret Plate
Oil Pad
B3 Barudan machine oil
Clear (mineral) oil for sewing machinery
*Wipe lightly with cotton swab saturated in
oil.
Once a month
Needle Bar Crank Rod C1 Bearing oil Once a week
Take-Up Drive Lever C2
Needle Bar Drive Lever (2) C3
Needle Bar Drive Links (3) C4
Needle Bar Driving Link C5
Needle Bar Driving Block C6 Bearing oil Once a month
Take-Up Lever E1 Lithium grease spray Every 3 months
Take-Up Lever Cam
Groove
E2
Presser Foot Cam (2) E3
H/V Linear Bearing Rails E4 Lithium grease spray Every 3 months
Pantograph Guide Shaft
(not pictured, only on 2-8
head models)
Color Change Cam Groove
(not pictured)
Lower Connecting Gear F1 Wheel bearing grease Every 3 months
2-6 X Series Mechanical Guide
