９‐３
Example 1: One server PC and one Barudan XS series embroidery machine
(Using a Cross LAN cable.)
Server PC XS Automat
Example 2: One server PC and multiple Barudan XR series embroidery machines
(Using a straight LAN cable.)
Server PC XS Automat
Cross LAN cable
Straight LAN cable
Straight LAN cable
Straight LAN cable
Straight LAN cable
