Icon Parameter
Function/Action
Range Of
Value
Default
Value
14
Swing
The distance in tenths of millimeters that is added
or subtracted from the length of a stitch. This
added or subtracted length is only applied to
stitches that have a change in direction from the
previous stitch. Therefore, this parameter has the
effect of increasing/decreasing the width of a satin
stitch, like typical lettering. This parameter has
also effects the width of a tatami stitch.
E.g.. If set to 1 (0.1mm/one each side), the width o
a satin stitch expanded to 0.2mm wider than
before.
Note: If you want to add/subtract the length of
stitch one direction only, sets at 1 or 2, “
22 Swin
Type” in Program as follows.
0 = Increase/decrease width in both directions.
1 =Increase/decrease width in the Vertical
direction only.
2 = Increase/decrease width in the Horizontal
direction only.
-15 - +15
[0.1mm]
0
15
Frame Start
Determines when panto. starts to move in relation
to the needle (degree wheel setting).
*Parameter changes may improve thread break
problems and stitch quality.
Refer: If set to 70, the Pantograph starts moving
at 70 degrees after the needle penetrated (at 300
degrees).
45- 135
[degree]
70
16
SF
(Spectacle
Frame)
(Optional
Frame being
used in the
USA )
Sets the m/c up for a spectacle frame allowing you
to execute pantograph movements exactly as
programmed.
0 = condenses the programmed pantograph
movement (Jump stitches).
1 = M/C moves per actual programmed
pantograph movements. *Perimeter trace,
Origin key, Frame
(#10 in program), Seeking origin movement
when the m/c powered On, are all disabled
with setting when set to 1. (DS V1.40 R00 ~)
2 = M/C moves per actual programmed
pantograph movements.
*Set to 1 to avoid hitting the pressure foot when
using spectacle or sock frames.
0 - 2 0
17
Needle Down
Determines if the needle is lowered after a thread
break for easier threading.
0 - 1 1
