３‐１２
6-2. Machine Information screen
Shows the condition of the machine.
A ：Shows TOP when the main shaft is at the correct stop position.
B ：Shows when the network is connected.
Shows when the network is disconnected.
C ：The height of the presser foot (Optional device)
D ：The current number of the selected needle
E ：The number of the group registered (When WS system is active)
F Shows the traveling distance of the pantograph frame.
Inc ：The increment traveling distance the from last movement or stitch made.
Abs ：The absolute traveling distance from the Start point to the current point.
A
B
C
D
E
F
