５‐６
Folders are divided into the following 4 types.
1) FDR Folder
- This folder is shown as
on the Automat.
- Stores design data in FDR format (.U01)
- 100 designs can be saved in a FDR folder.
2) PRJ Folder
- This folder is shown as
on the Automat.
- Stores design data in Network/ PRF format.
- 100 designs can be saved in a PRJ folder.
3) XSB Folder
- This folder is shown as
on the Automat.
- Backs up all the designs in memory in the Automat.
- Merging is not available.
4) TFD Folder
- This folder is shown as
on the Automat
- Stores design data in TFD format (.DST and .DSB)
- This file cannot be created on the Automat.
*When you make a folder on a USB Flash Drive, make sure the folder has one of the
following format file extensions:
Example) ABC．fdr （FDR folder）
ABC．prj （PRJ folder）
ABC．xsb （XSB folder）
ABC．tfd （TFD folder）
*NOTE: Do not edit the “System” folder in the USB Flash Drive. It may damage the system
software.
