The design information screen has the following contents.
Design No. ：Memory location of the design
Design Name：Name of the design
Stitch Count ：Total stitch count of the design
SIZE ：Distance between the overall dimensions of the design measured in
tenths of millimeters.
PASS ：Distance between the start and end points, shown as horizontal
and vertical values, measured in tenths of millimeters.
P１ ：Distance from the start point to the bottom left corner of the design,
measured in tenths of millimeters.
P２ ：Distance between the start point and the top right corner of the pattern
measured in tenths of millimeters.
V scale ：”V scale” of the Program Settings.
H scale ：”H scale” of the Program Settings.
Angle ：”Angle” of the Program Settings.
A ：Shows one of the icons shown below to indicate special conditions of the
design.
4. Press the A-key below the icon to show the Needle drop points of the selected
design.
Press the A-key below the icon again to go back to the previous display.
5. Press the C-key below the icon to show the design overview of before and after
of the Program changes.
* When the Program has not been changed, it is not displayed.
6. Press the G-key below the
icon to change the design color.
