Installation
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11
107
of 218
7
X1 Service interface, see ZX1 - Service interface– on page 120
X2 Digital in- and outputs e. g. pulse enable,
see ZX2 - Digital inputs/outputs– on page 121
X2:5 Input pulse enable, Low: not enabled, High: enabled (operation possible)
X3, X4 Connections for fieldbus EtherCAT
®
, VARAN, CANopen
®
, POWERLINK
®
, according to
version, also see ZX3 / X4 - fieldbus connection– on page 122
X6 Analog in- and outputs,
see ZX6 - analog inputs/outputs– on page 126
X7 Encoder evaluation,
see ZX7 - encoder connection– from page 127
X101 Connection motor temperature
see ZX101 - motor temperature– on page 143
X102 Connection STO
see ZX102 - safe torque off - option– on page 143
X107 Motor, also see ZRequirements to the motor– on page 28 and
ZX107 - motor connection– on page 144
X200 Connections for the 24 V-voltage supply (SELV/PELV),
see ZRequirements to the control voltage / 24 V-supply– on page 28 and ZX200 - 24V
voltage supply– on page 137
X203 Connection for DC link, see ZX202, X203, X205 - power supply, DC link, ballast resistor
connection– on page 138
X205 Connection for the DC-link, see ZX202, X203, X205 - power supply, DC link, ballast resis-
tor connection– on page 138
X300 Signal bus, connection to further units
see ZX300 - signal bus– on page 140
F1 Fuse DC link
F2 Fuse for the 24 V-voltage supply
PE PE connection,
see ZPE connection and RCD compatibility– from page 89 and
ZPE connections BM3200, BM3300 rear panel– on page 145
NOTE!
In order to comply with the standard, at the PE connection, per cable lug one nut M5
must be used!
