Dimensions
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11 Baumüller Nürnberg GmbH
24
of 218
3.1
3.1.1 Dimensions BM3000
70

212

Figure 4: Dimensions BM3000
*) Consider minimum space,
ZCooling– on page 34.
