Installation
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11
97
of 218
7
7.11 Installation procedure BM3200, BM3300
h All cables must be installed EMC-compatible.
h Connect cable (see ZConnecting diagrams– from page 98).
(Observe the allowable torque!)
The installation consists of the following steps:
1 Connect motor to the terminals 1U2, 1V2, 1W2, PE.
Consider the appropriate phase connection (rotational direction)
Consider the allowable torques!
Connection data see ZX107 - motor connection– on page 144.
2 Connect fuses (F1), also see ZFuses– from page 191
3 Connect device via the power supply input terminals
BM32XX-XT, BM33XX-XT
three-phase: 1U1, 1V1 and 1W1
at reduced power also single-phase possible: 1U1 and 1W1
BM32XX-XE, BM33XX-XE
single-phase: L and N
Connection data see ZX202, X203, X205 - power supply, DC link, ballast resistor
connection– on page 138.
4 Connect the protection conductor to the PE connection (a permanent PE connection
is compulsory),
also see ZPE connections BM3200, BM3300 rear panel– on page 145.
5 Connect 24 V-supply via terminals X200 -1, X200 -2
Connection data see ZX200 - 24V voltage supply– on page 137.
6 Connect signal bus X300 (see ZX300 - signal bus– from page 140)
7 Connect encoder
(encoder types and pin assignment see ZX7 - encoder connection– from page 127)
DANGER!
Risk of fatal injury from electrical current!
Parts under voltage are dangerous to life.
Therefore:
m Assure, that the device and the parts (e. g. power cables), which are mounted as
well as the mounting range are de-energized during mounting.
NOTE!
The plugging and pulling of the energized encoder cable is not permitted and can
cause a destruction.
Therefore, the 24V-supply voltage must be switched off before and the connector
must be interlocked.
