Baumuller b maXX 3000 - Cable Signal Bus; Varan, Powerlink

Accessories and Spare Parts
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11
181
of 218
11
11.1.6 Cable signal bus
BM3XXX-XXXX-XXXXX[-X]-XXX1X
up to 12 devices can be connected
or
BM3XXX-XXXX-XXXXX[-X]-XXX2X
up to 30 devices can be connected.
Part No.
Flat Cable Holder
Richco FCCS-2
430152
11.1.7 Cables - EtherCAT
®
, VARAN, POWERLINK
®
.
m Eth
ernet-connection Cables, Type: Patch cable, STP
Type Length [mm] Part No.
K-ETH-33-0-0,5 0.5 325160
K-ETH-33-0-01 1 325161
K-ETH-33-0-02 2 325162
K-ETH-33-0-03 3 325163
K-ETH-33-0-04 4 325317
K-ETH-33-0-05 5 325164
K-ETH-33-0-10 10 325165
other lengths on request
NOTE!
The
signal bus cables are not included in the delivery scope and must be ordered
separately.
Type Part No.
Signal bus cable 10-pin BM320X, BM330X 426781
Signal bus cable 10-pin BM321X, BM331X 426782
NOTE!
Dependent on the type of the used device
