Installation
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11
89
of 218
7
7.6 PE connection and RCD compatibility
Depending on the functional principle, leakage current >3.5 mA
AC
or >10 mA
DC
can flow
through the protective conductor. Consequently, a PE connection in accordance with EN
61800-5-1 is specified.
7.7 Installation requirements with regard to EMC stability
DANGER!
Risk of fatal injury from electrical current!
This product can cause direct and/or alternating current in the protective ground con-
ductor.
The leakage current, due to the functional principle of the device, can lead to prema-
ture triggering of the fault current protective device or generally prevent triggering of
it.
Therefore:
m Wherever a differential current device (RCD) is used for protection in case of direct
or indirect contact, only an RCD of the type B is permissible to provide current to
this product.
m Otherwise a different protective measure must be utilized, such as separation from
the surroundings by means of double or enhanced isolation, or separation from the
power supply network by means of an isolating transformer, for example.
NOTE!
The emission of radio frequency interference (RFI) is to a great extent dependent on
the wiring, spatial expansiveness and the arrangement of the components in the sys-
tem. Ensuring electromagnetic compatibility compliance in accordance with legal re-
quirements is therefore only possible on the completely assembled system and is
thus the responsibility of the system manufacturer or proprietor (re Art. 6, Par. 9 of
the EMVG; European EMC law).
NOTE!
The important information on EMC-compliant installation can be found in this Instruc-
tion handbook. Additional notes on building a CE-compliant system, that are impera-
tive to take heed of, can be found in the Baumüller Instruction handbook „Filters for
mains applications“, 5.09010. This manual can be obtained from Baumüller
Nürnberg GmbH.
