Baumuller b maXX 3000 User Manual

Design and Function
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11
53
of 218
4
4.2.3 Type code
The type code has the format:
BM3XXX-XXXX-XXXXX[-X]-XXXXX[-S0X]-XX[-XX][-EXX][-#XX].
The type code is explained in the following table.
BM3XXX-XXXX-XXXXX[-X]-XXXXX[-S0X]-XX[-XX][-EXX][-#XX] Device generation
BM3XXX-XXXX-XXXXX[-X]-XXXXX[-S0X]-XX[-XX][-EXX][-#XX] Device design
0: Mains rectifier unit
2: Compact Servo unit
3: Compact Servo unit safety
BM3XXX-XXXX-XXXXX[-X]-XXXXX[-S0X]-XX[-XX][-EXX][-#XX] Housing size
0 to 1: see ZDimensions– from page 23.
BM3XXX-XXXX-XXXXX[-X]-XXXXX[-S0X]-XX[-XX][-EXX][-#XX] Current grading (output rated current)
see ZElectrical data– from page 35
BM3XXX-XXXX-XXXXX[-X]-XXXXX[-S0X]-XX[-XX][-EXX][-#XX] Type of cooling
S: Air-cooled with air supply and air exhaust 
in the control cabinet
C: Cold plate
BM3XXX-XXXX-XXXXX[-X]-XXXXX[-S0X]-XX[-XX][-EXX][-#XX] Type of power supply
T: Grounded TN or TT power supply network
E: single phase power supply only
G: Grounded delta systems, IT systems,
grounded TN or TT systems
BM3XXX-XXXX-XXXXX[-X]-XXXXX[-S0X]-XX[-XX][-EXX][-#XX] Type of electronic safety relay
(only BM3300)
0: No safety relay
2: Double safety relay
BM3XXX-XXXX-XXXXX[-X]-XXXXX[-S0X]-XX[-XX][-EXX][-#XX] Design
0: Standard
BM3XXX-XXXX-XXXXX[-X]-XXXXX[-S0X]-XX[-XX][-EXX][-#XX] Hardware design basic unit
0XX: Unit with ballast transistor, U
ZK
= 540 V
210: Mains rectifier unit, without ballast transistor,
U
ZK
= 540 V
BM3XXX-XXXX-XXXXX[-X]-XXXXX[-S0X]-XX[-XX][-EXX][-#XX] Special design basic unit
00: Standard
BM3XXX-XXXX-XXXXX[-X]-XXXXX[-S0X]-XX[-XX][-EXX][-#XX] Ballast resistor optional
B: Ballast resistor integrated
E, -: Without internal ballast resistor, 
connection for external ballast resistor
