Accessories and Spare Parts
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11
183
of 218
11
11.1.10 Encoder cables
Selection of the
encoder cables
The trailing cables are suitable for mobile deployment, for example in mobile cable han-
dlers. In addition, the cable sheath can be used in environments with acids and bases
(e.g. coolant).
With servo motors using the Resolver encoder system, the temperature sensor is con-
nected to the device via the encoder cable. Additional technical data, connector assign-
ments, application notes and Part numbers can be found in the motor documentation.
Cables pre-assembled - trailing type; CE UL/CSA, Halogen-free, according to IEC 60754-1, Sili-
cone-free, FCKW-free, RoHS compliant, additional lengths upon request.
Length
Resolver Encoder with
HIPERFACE
®
Sine-/square wave
incremental encoder
Part No. Part No. Part No.
speedtec
®
speedtec
®
speedtec
®
1 m 429914 448746 429958 448761 430015 448777
2 m 429915 448747 429959 448762 430016 448778
3 m 429916 448748 429960 448763 430017 448779
5 m 429917 448749 429961 448764 430018 448780
7 m 429918 448750 429962 448765 430019 448781
10 m 429919 448751 429963 448766 430020 448782
15 m 429920 448752 429964 448767 430021 448783
20 m 429921 448753 429965 448768 430022 448784
25 m 429922 448754 429966 448769 430023 448785
30 m 429923 448755 429967 448770 430024 448786
35 m 429924 448756 429968 448772 430025 448787
40 m 429925 448757 429969 448773 430026 448788
50 m 429926 448758 429970 448774 430027 448789
75 m 429927 448759 429971 448775 430028 448790
