Baumuller b maXX 3000 - 3 Technical Data; Dimensions

23
of 218
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11
3TECHNICAL DATA
3.1 Dimensions
With the help of the following figures, the space requirements in the control cabinet are
determined. In order to execute the necessary drilling/section please refer to ZDrilling
templates– from page 77.
NOTE!
All dimensions in mm.
