Connections

Instruction handbook b maXX BM3000, BM3200, BM3300

Document no. 5.11018.11 Baumüller Nürnberg GmbH

142

of 218

7.14

7.14.3 Connections BM3200, BM3300 at the bottom

Figure 58: Connections at the bottom

X101:

Connection

motor temperature

X102:

STO-connection

X107:

Motor connection

1U2, 1V2, 1W2
