Baumuller b maXX 3000 User Manual

Cables
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11 Baumüller Nürnberg GmbH
178
of 218
11.1
11.1.2 Cable device-motor
Device Cross-section Maximum Length
1)
Connection at Device
2)
BM320X
BM330X
BM321X
BM331X
4 x 1 to 4 mm
2
(AWG 28 - 12)
max. 50 m flexible cable
with/witho
ut wire end ferrule
(screw contact)
1)
Only with a Baumüller cable with this maximum length and with a Baumüller mains filter it can be expected that the limit values of the
EMC-product standard EN_61800-3 can be complied with. If n-parallel-laid motor cables are used, then the maximum length is to be
reduced by the factor 1/n.
2)
With Baumüller cables with this maximum length and the use of Baumüller mains filters, it can be expected that the limit values of the
EMC-regulation is complied with.
11.1.3 Hybrid cable device-encoder-motor
Selection The trailing cables are suitable for mobile deployment, for example in mobile cable han-
dlers. In addition, the cable sheath can be used in environments with acids and bases
(e.g. coolant).
The encoder wires for DSL Hiperface
®
encoders are connected with the device.
Cables pre-assembled - trailing
type; CE UL/CSA, Halogen-free, Silicone-free, FCKW-free,
RoHS compliant, additional lengths upon request.
Length
Hybrid cable motor DSL Hiperface
®
15 A
speedtec
®
M23
Part No.
3 m 464201
5 m 464202
7 m 464203
10 m 464204
15 m 464205
20 m 464206
25 m 464207
30 m 464208
35 m 464209
40 m 464210
50 m 464211
60 m 464212
