7.14 Connections
7.14.1 BM3200, BM3300 front side
X1:
Service interface
X2
Di
gital
IOs
X3 / X4:
Fieldbus
EtherCAT
®
,
VARAN
CANopen
®
,
POWERLINK
®
X7:
Encoder
co
nnection
X6:
Analog
IOs
Figure 52: Connections front side
7.14.1.1 X1 - Service interface
X1
NOTE!
Only, the service cable BM5-K-USB-XXX must
be used with the service interface X1, also see
ZService interface– on page 150, max. trans-
mission rate 920 kBaud.
X1: Service interface
