6.2 Preparing for mounting
Based on the project planning and the drilling templates (see ZDrilling templates– from
page 77), the positions of the attachment drill holes can be determined.
NOTICE!
Property damage due to conductive contamination.
Therefore:
m When performing installation work of any kind, it must be ensured that no foreign
material (e.g. drill shavings, copper strands, etc.) gets into the device as a result.
m If possible, the drilling of the holes should be done before mounting the device and
the configuring of the cables should take place outside of the control cabinet. If this
is not possible, the device must be appropriately covered.
Remove this covering again prior to starting operation without fail!
CAUTION!
Eye injury due to flung particles.
Metal particles are flung when making the drill holes and the cutout sections.
Therefore:
Wear safety goggles!
