Monitoring functions
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11 Baumüller Nürnberg GmbH
172
of 218
10.2
10.2 Monitoring functions
Monitoring function Warning/Error
Threshold settable Warning Warning reaction Error Error reaction
Phase monitoring Phase failure - X
2)
X
2)
Power supply failure - X - X
2)
Overcurrent Overcurrent motor - - - X IS
DC-link DC-link overvoltage - - - X IS
DC-link undervoltage - - - X
IS
Ixt-threshold Peak current not possible, at present - X - - -
Temperature
heat sink
Temperature > threshold 1 X X - - -
Temperature > switch-off threshold - - - X IS
Temperature 
Internal space of device
Temperature > threshold 1 X X - - -
Temperature > switch-off threshold - - - X IS
Temperature 
motor
I
2
t-threshold exceeded - - - X IS
1)
Threshold 1 exceeded
4)
XX - - -
Threshold 2 exceeded
4)
XX - - -
Short-circuit sensor / T < 30 °C
4)
---XIS
1)
Sensor is not connected / T > 250 °C
4)
---XIS
1)
Maximum temperature exceeded
2)
X- -XIS
1)
Position controller Position deviation error, dynamic mode X - - X -
Position deviation error, static mode X - - X -
Controller synchronization Controller not synchronous with external signal - X - X
1)
Encoder Overspeed X - - X IS
3)
Cyclic set value transmis-
sion to the fieldbus
Time-out at transmission X - - X
1)
Block monitoring Drive blocked - - - X IS
Signal bus Power supply ready - - - X
1)
1)
Monitoring can be switched-off
2)
Time/operation until pulse inhibit can be set
3)
Threshold can be set
4)
Only, if a KTY/PT1000-sensor is used
IS: Pulse inhibit
X: implemented
-: not possible
