Electrical data
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11 Baumüller Nürnberg GmbH
40
of 218
3.4
3.4.4 Electrical data BM3X12-XT, BM3X13-XT, 400 V
a)
with internal ballast resistor BM3X02-XTXX-XXXXX-B-XXXXX- 
b)
without internal ballast resistor BM3X02-XTXX-XXXXX-E-XXXXX-
BM3X12
3-phase/3 x 400 V
BM3X13
3-phase/3 x 400 V
Input rated power output
1)
5.4 kVA 6.9 kVA
Input rated current (I
eff
)
1) 2) 3)
7.8 A 10.4 A
Distortion factor of the input current (THD
I
)
1)
118 % 77 %
Input peak current (I
eff
)
1) 2) 3)
20.8 A 20.8 A
DC-link voltage power supply-dependent/rating 540 V
DC
DC-link capacitance (internal) 235 µF
DC-link capacitance (external)
(only devices BM3X0X-XTXX-XXXXX-B)
see DC link connection of additional capaci-
ties from ZPage 116–
DC-link discharge time (internal DC-link capacitance) ca. 450 s
Output voltage
(U
AC
)
1) 4)
0 ... 400 V
Output frequency at 4 kHz
5) 6)
0 ... 450 Hz
Output rated current
(I
AC
)
1)4)7)8)9)
at 2 kHz
5)
6.5 A 10 A
Output rated current (I
AC
)
1)4)7)8)9)
at 4 kHz
5)
6.5 A 10 A
Output rated current
(I
AC
)
1)4)7)8)9)
at 8 kHz
5)
4.8 A 7 A
Output rated current (I
AC
)
1)4)7)8)9)
at 16 kHz
5)
3.4 A 5 A
Output peak current (I
AC
)
1)4)7)8)9)
at 2 kHz
5)
20 A
Output peak current
(I
AC
)
1)4)7)8)9)
at 4 kHz
5)
20 A
Output peak current (I
AC
)
1)4)7)8)9)
at 8 kHz
5)
14 A
Output peak current
(I
AC
)
1)4)7)8)9)
at 16 kHz
5)
10 A
Max. peak current time 10 s
Ballast start-up voltage 785 V
Ballast peak power, internal ballast resistor
a)
1200 W for max. 150 ms
Average ballast power, internal ballast resistor
a)
100 W
Permitted ballast current (Î), external ballast resistor
b)
max. 12.8 A
Ballast resistor, external ballast resistor
b)
 61 
Ballast peak power, external ballast resistor
b)
10 kW
Permitted continuous power of external ballast resistor
b)
5 kW
Switch on ready-to-operate after  4 s
Max. upload time  0.5 s
Power loss referring to power connection 70 W
Power loss referring to control voltage max. 30 W
Cooling air requirement 11 m
3
/h
