Baumuller b maXX 3000 User Manual

Technical Data
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11
39
of 218
3
Footnotes see ZPage 43–.
BM3X02
1-phase/1 x 400 V
BM3X03
1-phase/1 x 400 V
BM3X04
1-phase/1 x 400 V
Input rated power output
1)
1.2 kVA 1.4 kVA
Input rated current (I
eff
)
1) 2) 3)
4.2 A 5.6 A
Distortion factor of the input current (THD
I
)
1)
130 %
Input peak current (I
eff
)
1) 2) 3)
5.6 A
DC-link voltage power supply-dependent/rating 540 V
DC
DC-link capacitance (internal), external not permitted 235 µF
DC-link discharge time (internal DC-link capacitance) ca. 450 s
Output voltage
(U
AC
)
1) 4)
0 ... 400 V
Output frequency at 4 kHz
5) 6)
0 ... 450 Hz
Output rated current
(I
AC
)
1)4)7)8)9)
at 2 kHz
5)
2 A
Output rated current (I
AC
)
1)4)7)8)9)
at 4 kHz
5)
2 A
Output rated current
(I
AC
)
1)4)7)8)9)
at 8 kHz
5)
2 A
Output rated current (I
AC
)
1)4)7)8)9)
at 16 kHz
5)
2 A
Output peak current (I
AC
)
1)4)7)8)9)
at 2 kHz
5)
2 A
Output peak current
(I
AC
)
1)4)7)8)9)
at 4 kHz
5)
2 A
Output peak current (I
AC
)
1)4)7)8)9)
at 8 kHz
5)
2 A
Output peak current
(I
AC
)
1)4)7)8)9)
at 16 kHz
5)
2 A
Ballast start-up voltage 785 V
Ballast peak power, internal ballast resistor
a)
1200 W for max. 150 ms
Average ballast power, internal ballast resistor
a)
100 W
Permitted ballast current (Î), external ballast resistor
b)
max. 7.0 A
Ballast resistor, external ballast resistor
b)
 111 
Ballast peak power, external ballast resistor
b)
5.5 kW
Permitted continuous power of external ballast resistor
b)
2.5 kW
Switch on ready-to-operate after  4 s
Max. upload time  0,5 s
Power loss referring to power connection 50 W
Power loss referring to control voltage max. 30 W
Cooling air requirement 11 m
3
/h
