Installation procedure BM3000
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11 Baumüller Nürnberg GmbH
96
of 218
7.10
7.10 Installation procedure BM3000
h All cables must be installed EMC-compatible.
h Connect cable (see ZConnecting diagrams– from page 98).
(Observe the allowable torque!)
The installation consists of the following steps:
1 Connect fuses (F1), also see ZFuses– from page 191.
2 Connect BM3000 via the power supply input terminals 
three-phase: 1U1, 1V1 and 1W1
Connection data see ZConnections BM3000– on page 119.
3 Connect the protection conductor to the PE connection (a permanent PE connection
is compulsory), also see
ZConnections BM3000– on page 119.
4 Connect input signal for bridging relay X100 (see ZConnections BM3000– on page
119)
5 Connect further axis units via the DC link connection.
DANGER!
Risk of fatal injury from electrical current!
Parts under voltage are dangerous to life.
Therefore:
m Assure, that the device and the parts (e. g. power cables), which are mounted as
well as the mounting range are de-energized during mounting.
