Installation
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11
115
of 218
7
Installation notes
Additional notes for installation
n all devices must be parametrized „supply via power supply“
n a de
struction of a single device can result in secondary damage of the two other
devices
n a comb
ined operation on 2 phases and 3 phases is not allowed,
it is not allowed to enable a single device in case of one or several fuses have been
trip
ped (danger is overload).
n this applic
ation is only valid for the following devices
BM3201, BM3202, BM3203, BM3204, BM3211, BM3212, BM3213,
BM3301, BM3302, BM3303, BM3304, BM3311, BM3312, BM3313
n no further devices or components (e.g. external DC link capacitors) are allowed to be
connected to the DC link
F1, F2, F2 Fuses (cable protection+ device protection), separate fuse for every device
F1
0-F15 Option: a destruction of the next devices can be avoided
F4 Fuse for the 24 V-voltage supply
Filter Separate filter for every device,
(a shared filter can be possible, but its function is not guaranteed)
L
1a
, L
2a
, L
3a
,Choke, u
K
= 2 - 4 %, separate choke for every device, the use of the same type of chokes
is required
NOTE!
No chokes are required if the power demand of all devices together is at no time
higher than 5 kW.
NOTICE!
Only the following devices can be combined
BM3203, BM3204, BM3212, BM3213, BM3303, BM3304, BM3312 and BM3313
or
BM3201, BM3202, BM3211, BM3301, BM3302 and BM3311.
Other interconnections are forbidden!
