Installation
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11
139
of 218
7
X202 BM3XXX-XTXX-XXXXX-B-XXXXX-, device with internal ballast resistor
Power supply
1U1, 1V1, 1W1
X202 BM3XXX-XE, device with/without internal ballast resistor
Power supply
L, N
X203 BM3XXX-XTXX-XXXXX-E-XXXXX-, device without internal ballast resistor
Power supply
1U1, 1V1, 1W1
DC link connection
1C1, 1D1
Ballast resistor connection
1C1, Ba-
X205 BM3XXX-XTXX-XXXXX-B-XXXXX-, device with internal ballast resistor
BM3XXX-XEXX-XXXXX-B-XXXXX-, device with internal ballast resistor
DC link connection
1C1, 1D1
X205 BM3XXX-XEXX-XXXXX-E-XXXXX-, device without internal ballast resistor
DC link connection
1C1, 1D1
Ballast resistor connection
1C1, Ba-
PE See ZPE connections BM3200, BM3300 rear panel– from page 145.
Connection system Loading capacity
Connector,
screw terminal
Connector max. 20 A
Minimum Maximum
Conductor cross-section
single-wire
flexible
with wire end ferrule 
(with/without shroud)
0.08 mm² / AWG28
0.08 mm² / AWG28
0.2 mm²
4 mm² / AWG12
4 mm² / AWG12
2.5 mm²
Tightening torque 0.4 Nm 0.5 Nm
Screwdriver blade 0.6 x 3.5 mm
Remove insulation 7 mm / 0.9 in
