Design and Function
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11
65
of 218
4
LEDs CANopen
®
Type code BM3200, BM3300 with CANopen
®
:
BM3XXX-XXXX-XXXXX[-X]-3XXXX
[-S0X]-XX[-XX][-EXX][-#XX]
LEDs without function.
LEDs
POWERLINK
®
Type code BM3200, BM3300 with POWERLINK
®
BM3XXX-XXXX-XXXXX[-X]-4XXXX
[-S0X]-XX[-XX][-EXX][-#XX]
Naming on the
front plate
H31 (green) X3 Link / Act Off: No connection
On: Connection
Blinking: Data transfer
H32 (yellow) ERROR Off: NMT_CT3, NMT_CT7, NMT_GT2
On: NMT_CT11, NMT_GT6
Blinking: Configuration error
(e.g. address setting)
H41 (green) X4 Link / Act Off: No connection
On: Connection
Blinking: Data transfer
H42 (green) STATUS Off: NMT_GS_OFF, NMT_GS_INITIALISATION,
NMT_CS_NOT_ACTIVE
50 ms off /
50 ms on: NMT_CS_BASIC_ETHERNET
200 ms on /
1 s off: NMT_CS_PRE_OPERATIONAL_1
2 x 200 ms on /
1 s off: NMT_CS_PRE_OPERATIONAL_2
3 x 200 ms on /
1 s off: NMT_CS_READY_TO_OPERATE
On: NMT_CS_OPERATIONAL
200 ms on /
200 ms off: NMT_CS_STOPPED
Meaning Blinking pattern
