Mounting
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11
81
of 218
6
The required screws and washers for the mounting are specified below the figure.
Complete mounting as follows:
1 Provide suitable fixing material.
2 Mo
unt device.
n check the
surface quality of device’s rear panel/mounting plate, see ZMechanical
data of the mounting plate for cold plate– on p
age 80
Mount device h Mount BM3000 horizontally only.
Figure 29: Mounting instruction BM3000
Device BM3000
A - Screws 2 x M5
B - Washers 2 x (5,3 x 10)
