Volume 1 10 Source Replacement
1
Install new source  Using a pair of pliers, take the new source out of the transport
shielding and place it into the operating shielding.
 Attach the brass cover (2) again after you have checked if the
O-ring seal is clean and undamaged.
 Attach head flange again and carefully secure it with screws.
 Check the proper ON/OFF function.
 Carefully close the transport shielding again, after you have put
the old source into the transport shielding.
 Set up the operating shieldings as planned. With multi-part
shieldings be sure to observe the correct order.
Replace the type label  Replace the type label on the shielding or attach the new source
number.
 For multi-part rod source shieldings, an additional label has to
be attached to the bottom shielding showing the overall activ-
ity.
IMPORTANT
The special regulations regarding labeling and transport of the
shielding back to the manufacturer have to be observed. If in
doubt, please contact BERTHOLD TECHNOLOGIES's Source Trans-
port Manager.
This completes the rod source replacement.
