Menu Structure Volume 3
5 Loop Current Mode Indicates whether the current output is active or frozen. The follow-
ing displays are possible:
• ENABLED
The current output is active.
• DISABLED
The current output is frozen.
The current output is frozen in the following cases:
– if it is set to fault current
– in multi-drop mode (
Set Poll Address, see page 3-362)
–in test mode
6 Loop test Allows you to selectively output current values at the current out-
put. Thus you can check the correct function of the current output
and the display value in the process control system. Enter the
desired value in mA.
2.41 Plateau
Menu path: Device Config Setup Service Plateau.
This menu leads to the plateau measurement and to the display of
the plateau values.
1 Plateau Measurement Leads to the plateau measurement (page 3-371).
2 Plateau View Enables the display of the plateau data in a table or as a plateau
curve.
3 Plateau Information General information on the plateau measurement.
