Menu Structure Volume 3
2.32 Temp. Threshold Settings
Menu path: Device Config Setup I/O Setup Digital
Output Temp. Threshold Settings.
1 Temp. Upper Limit Upper limit value for the detector temperature.
An alarm may be signaled via the digital output if this temperature
is exceeded. To do this, set the digital output to the function DET.
TEMP. The alarm is also signaled when the minimum detector tem-
perature (Temp. Lower Limit) is not reached.
You can use this feature, for example, as a pre-alarm, for the
detection of an over-temperature, or control the cooling water
cycle of the detector so that the cooling water flow is started at ele-
vated temperature.
2 Temp. Lower Limit Lower limit value for the detector temperature.
An alarm may be signaled via the digital output if this temperature
is not reached. To do this, set the digital output to the function DET.
TEMP. The alarm is also signaled when the maximum detector tem-
perature (Temp. Lower Limit) is exceeded.
You can use this function as a pre-alarm for under-temperature, so
that a possibly connected cooling water system does not freeze, or
a heater is turned on.
3 Temp. Hysteresis Hysteresis for the temperature limit values.
4 Temp. Unit Unit for the detector temperature. The temperature can be indi-
cated in Fahrenheit or in Celsius.
5 Device Temp. Displays the temperature inside the detector.
