54733-10BA2L
3 – 394 02.2017
5 Calibration Volume 3
5.1 Preparing Calibration
For correct calibration of the measuring system, you have to ensure
that the detector and basic settings are correct.
Turn the HART
®
Communicator on.
After power on, the Start menu appears.
Push HOME to return from any level back to the Start menu.
If the detector has been in stock for a long time, it may happen that
the internal clock no longer displays the current date. In this case,
the error message 105 Real time clock not valid is displayed. Update
the date and time to reset the error message (see chapter 2.12,
page 3-323).
If you are sure that the detector and basic configuration are correct,
you can start with the calibration of the measuring system immedi-
ately as described in chapter 5.2.
Otherwise proceed as follows:
If the device is still locked with a password, undo the password
protection (see page 3-376).
Reset the detector to factory defaults (see chapter 5.1.2)
Adjust the value for HV default (see page 3-395). This is usu-
ally not necessary, since the detector is factory-calibrated.
