SENSseries LB 480 Level measurement
BERTHOLD TECHNOLOGIES GmbH & Co. KG
3 – 307
Volume 3 2 Menu Structure
3
2 Menu Structure
2.1 Information on the Menu Structure
The menu structure on the following pages provides an overview
over all functions of the SENSseries detectors. Using the page num-
bers indicated you can look up explanations on the function of each
menu item.
First ENTER then SEND To rule out incorrect entries, you always have to push the SEND
softkey immediately after you have entered a value via the ENTER
button. The SEND softkey is only visible after values have been
changed.
– Push ENTER to save edited values and parameters in the
Communicator.
– Push SEND to transfer all modified values from the Com-
municator to the detector.
The following sections assume that you:
• know how to work with the Communicator
• Volume 2 have read and understood ("Installing SENSseries")
of this User’s Manual.
