54733-10BA2L
1 – 16 02.2017
1 About this User’s Manual Volume 1
CSA Canadian Standard Association: sets norms and standards that are
important for Canada (and America), among other things, the
Directive for Explosion Protection and Low Voltage.
PMT Photomultiplier or only multiplier: converts the flashes of light gen-
erated by the radiation in the detector into electrical signals.
HV HV = High voltage
The multiplier is operated at high voltage, so that flashes of light
can be converted into electrical pulses.
The high-voltage control allows for measurements that are stable to
temperature and aging. Each multiplier has a slightly different sen-
sitivity, and must therefore be operated at a different high voltage.
active / passive (Source / Sink) Depending on the detector type, the current output can be config-
ured as a current source or current sink. The following terms are
used interchangeably:
• Current source: active / Source Mode
• Current sink: passive / Sink Mode
1.5 General Information
The most important safety measures are summarized in this vol-
ume. It supplements the appropriate provisions which the staff in
charge is obliged to follow.
Please pay attention to:
– the national safety and accident prevention regulations
– the national assembly and installation directions (for example,
EN 60079)
– the generally accepted engineering rules
– the information on transport, assembly, operation, service,
maintenance in this User’s Manual
– the safety instructions and information in this User’s Manual
and the enclosed technical drawings and wiring diagrams
– the parameters, limit values and the information on operating
and ambient conditions on the type labels and in the data
sheets
– the labels on the device
Depending on the field of application, the corresponding chapters
have to be taken into account.
