6 Functional Processes
The following chapter describes the major functional processes that
occur when working with the SENSseries.
6.1 Multidetector Operation
Prerequisite:
• Master is wired to the slave(s) as shown in the Technical Data.
• Master and slave(s) are supplied with mains voltage.
•HART
®
Communication with master is established.
The commissioning of the complete master-slave arrangement
(cascade) can now be performed on the master.
The slave detectors must be logged in at the master as follows.
 Select Device Config  Setup  Sensor Configuration 
Config Slave Detectors  Add Slave.
 Enter the address for the first detector (1-16). For the first
detector this is usually the "1".
 Select the slave function MULTI DETECTOR.
 Enter the device ID for each detector. The device ID can be
found on the type plate of each detector (3 to 5-digit number).
 If other slave detectors are connected, you have to repeat the
process with the other slave detectors.
 If an error message occurs during log-in, check whether the
connected detector is wired correctly and is powered by the
mains.
 At last, check your entries for the multi-detector operation
using the table, which you can access under Slave Table.
