54733-10BA2L
3 – 324 02.2017
Menu Structure Volume 3
2.13 Sensor Settings
Menu path: Device Config Setup Sensor Configuration
Sensor Settings.
1 Active Detector No. Choose the detector for which you want to display the current
values in this window.
• Detector No. = 0 shows the date and time of the master
detector.
• Detector No. = 1 shows the date and time of slave 1.
• Detector No. = 2 shows the date and time of slave 2.
etc.
2 Error Code Indicates if an error is present in the active detector.
If no error is present, then 0 is displayed here.
An error message is displayed with a three digit number. The cause
of the error and suggestions for correcting the error are described
in "Error Handling" in chapter 8.
3 Detector Device Id Shows the specific HART
®
device number of the active detector.
This information is set up by BERTHOLD TECHNOLOGIES and edited
be changed by the user.
4 Detector Code The currently selected detector code is displayed.
The detector code is crucial for the proper function of the automatic
HV control (high voltage control).
The detector code has already been set by BERTHOLD
TECHNOLOGIES. It is dependent on the scintillator size and the
detector type, see Volume 2, chapter 1.6, "Detector Codes", on
page 2-166.
