Menu Structure Volume 3
2.4 Live Display
1 Operating Mode Shows the current operating status.
The following states may occur:
• RUN
The measurement is in the normal measurement mode.
• WARNING
A warning message is displayed.
If the error is no longer displayed in Active Error, you can
check the error log (Device Config Diagnostic Log,
page 3-387). In chapter 8 on page 3-429 you find a list of pos-
sible causes and troubleshooting procedures.
• ERROR
An error is indicated.
If the error is no longer displayed in Active Error, you can
check the error log (Device Config Diagnostic Log,
page 3-387). In chapter 8 on page 3-429 you find a list of pos-
sible causes and troubleshooting procedures.
• SHUTDOWN
A serious error is indicated.
If the error is no longer displayed in Active Error, you can
check the error log (Device Config Diagnostic Log,
page 3-387).
In chapter 8 on page 3-429 you find a list of possible causes
and troubleshooting procedures. If the error does not disappear
after restart (power off and then on, or software reset, page 3-
363), then the detector must be replaced.
• HOLD
The measurement is in the hold state, which means that the
measured value and the current output signal is frozen. This
status can occur under the following conditions:
– the plateau recording is running
– interference radiation was detected
– the digital input is on Hold
• TEST
A test value is enabled, see chapter 2.39, page 3-366.
