2.55 Operating Status
Menu path: Diagnostic  Operating Status.
1 Device Status Displays the current device status (standard HART
®
command).
2 Ext dev status Shows the extended device status (standard HART
®
command,
page 3-382).
3 Device Variables Status Opens the menu showing the status of the detector variable (stan-
dard HART
®
command, page 3-383).
4 Config Change Status Opens the menu showing the number of changes (see page 3-
384).
5 Lock Dev Status Indicates to what extent the device is locked against access to the
HART
®
interface by other devices.
– Device is Locked
– Lock is Permanent
– Locked by Primary Master
6 Error Status Opens the menu providing an overview of the operating status of
the measurement (see page 3-383).
2.56 Ext dev status
Menu path: Diagnostic  Operating Status  Ext dev status.
Displays the current extended device status (standard HART
®
com-
mand).
– Maintenance required
The extended device status "Maintenance Required" is not
used.
– Device variable alert
This status is signaled if any of the following conditions exist:
– Primary Variable Out Of Limits
– Non-Primary Variable Out Of Limits
– Process Data Status
1
of a device variable is not in the status
GOOD
–Limit Status
1
of a device variable is not in the status
NOT_LIMITED
– Critical Power Failure
Not used
(Only applicable to rechargeable battery or battery-operated
devices.)
1. Process Data Status and Limit Status are included in the Device Variable Status.
