54733-10BA2L
2 – 294 02.2017
6 Accessories Volume 2
Material: … -3U and … -4U
KINETROL …-3U KINETROL …-4U
Housing Zinc die casting
Coating Epoxy resin, burned in
Sealing O-rings (Nitril)
Temperature range -25° C to +60° C -20° C to +80° C
Weight 1,4 kg
Cable inputs M20x1.5 M20x1,5; PG13,5; ½" NPT; 4-pole connector
(DIN 43650A)
Cable clamp Terminal cross-section 2.5 mm², grounded conductor terminal 2.5 mm², earthed conductor
clamp 4.0 mm²
Protection type IP54–65
View without housing cover
Optional cable clamps for con-
nection of a magnetic valve
Adjustable cams
Shaft
Shaft mounting bracket
