SENSseries LB 480 Level measurement
BERTHOLD TECHNOLOGIES GmbH & Co. KG
2 – 293
Volume 2 6 Accessories
2
Technical Specification / Electrical Wiring
… -3U 2 micro push-buttons
BARTEC 07-1501-6120-63 (closer) for drive size 02/03
BARTEC 07-1501-6130-63 (changer) for drive size 05-14
… -4U 2 micro push-buttons
Standard dimensions according to DIN41635
Volt Load (A)
AC DC Resistor inductive (max.)
250 7 5
125 7 5
up to 12 7 5
up to 24 1 1
up to 48 0.5 0.06
up to 250 0.3 0.03
Volt Load (A)
AC DC Resistor inductive (max.) Lamps
250 15 5 1.5
125 15 5 1.5
up to 12 15 5 1.5
up to 24 10 1 1
up to 48 3 0.06 0.3
up to 250 0.25 0.03 0.025
